7486 IC Quad 2 input XOR gate IC Exclusive OR Gate IC

Product Specifications

• Gate Type: EX-OR Gate
• Number of Gates count in one IC: 4 Gates
• Inputs Number per Gate: 2
• Pin type: through hole
• package type: PDIP-14
• Number of pins: 14
• Power Consumption: Low
• Package Contains: 1 x 7486 EXOR gate IC

7486 IC is a member of 74xxx series gate ICs and has the functionality of the EX-OR (Exclusive OR) gate or function. 7486 has 4 EX-OR gates of 2 inputs in 1 package.The internal gates in the ICs are made of Schottky Transistor of low power. Another name of this IC is ?quadruple 2 inputs EXOR gate?.

Specification

Large operating voltage

Its operating conditions are wide

Maximum Current that output can draw: 8mA

It  has TTL outputs

Its power consumption is low

The range of operating voltage: 4.75V to 5.5V

Maximum limit of voltage: 7V
